C&D Technologies 2XTHPC-29 SAN Flooded VLA Battery - C&D XT Plus Series
C&D Technologies XT Series batteries are engineered to deliver exceptional performance and long-term reliability. Utilizing proprietary design techniques and high-quality components, these batteries are built for reduced maintenance and extended service life. Designed for high performance in compact spaces, the XT Series is ideal for Uninterruptible Power Supply (UPS), switchgear, and control applications. Optimized for high-rate, short-duration discharge, the XT Series VLA batteries provide dependable, long-life backup power for critical UPS systems.
XT Plus is ideal for sites with frequent blackouts and brownouts or locations that require the batteries to be cycled frequently to test other system components.
Key Features & Benefits
- Low-maintenance lead-calcium alloy extends watering intervals
- Design is optimized for high-rate, short duration discharges
- Soft rubber post bushing minimizes stress on post seal, leak-free design using heli-arc process unique to C&D
- Electrical testing to 100% capacity assures performance of every battery
- Warranty for cycle duty or float service is available
- 20-year life expectancy in float service at 77°F (25°C) ambient temperature
Applications
- Data Centers
- Uninterruptible Power Supply (UPS)
- Telecommunications
- Energy and Infrastructure
- Network Operations Centers
- Industrial Hosting Sites
- Semiconductor Manufacturing
- Banks and Financial Markets
- Power Generation Plants
- Hospitals and Testing Laboratories
- Emergency 911 Response Centers
- Switchgear and Control
C&D 2XTHPC-29 SAN Construction Details
- Flooded Vented Lead Acid (VLA) Battery
- Flame retardant covers standard to enhance battery plant safety
- Hardened, lead-alloy terminals or copper-inserted posts provide better conductivity and tighter connections requiring less maintenance
- Available in Poly, Poly Tube, San, and San Tube
Specification Details for 2XTHPC-29 SAN by C&D
| ATTRIBUTES |
DETAILS |
General Info |
Chemistry |
Flooded Vented Lead Acid (VLA) |
Voltage |
4 V |
Capacity |
1379Ah @ 8 Hr Rate |
Cells Per Unit |
|
|
Dimensions
- Overall Length
- Overall Width
- Overall Height
|
15.27 inches / 388.00 mm
14.32 inches / 364.00 mm
22.92 inches / 582.00 mm
|
Weight |
504.00 lbs / 229.00 kgs |
Container Type |
SAN |
Terminal Type |
Two 5/8 inch x 2 inch (15.88 mm x 50.80 mm) copper blade posts with dual-bolt holes per cell
|
Design Life |
Up to 20-year float life at 77°F (25°C)
|
Warranty |
|
Electrical Specifications & Performance Characteristics |
Float Voltage |
2.21 to 2.22 VPC |
Operating Temperature Ranges |
Nominal: 77°F (25°C)
Recommended Operating Temperature: 60°F to 90°F (15°C to 32°C)
Operating Temperature Limits: 32°F to 120°F (0°C to 49°C)
|
Specific Gravity |
1.215 |
Electrolyte |
Sulfuric Acid |
Construction Details |
Container Material |
SAN
|
Cover Material |
High impact, flame retardant thermoplastic with tongue-and groove seal
Flammability ratings: UL94 V-0; ASTM D-635, self-extinguishing
Oxygen Index > 32
|
Safety Vent System |
Flame arrestor type with dust cover
|
Separators |
Microporous with fiberglass retaining mat
|
Certifications & Safety Compliances
Options & Accessories
- Contact a member of the Power Storage Solutions Sales Team for additional information on available options and accessories.
