C&D TEL Long Duration Series 12V 108Ah @ 8 Hr Rate AGM VRLA Battery
SKU:

TEL12-115FN

C&D TEL Long Duration Series 12V 108Ah @ 8 Hr Rate AGM VRLA Battery

**This product has been discontinued. See below for our recommended alternatives**

Need help planning a transition?
Our team is here to assist.

CONTACT US

Our Recommended Alternatives

Other models in this line

TEL12-105FNSG

$520.46

In Stock

TEL12-160F

$592.08

In Stock

TEL12-170FG

$555.15

Pre-order

TEL12-180F

$629.34

In Stock

TEL12-210F

$655.82

In Stock

TEL12-30

$191.85

In Stock

TEL12-45

$241.68

In Stock

TEL12-70

$285.62

In Stock

TEL12-80

$308.83

In Stock

TEL12-90

$335.80

In Stock

TEL6-180

$357.20

In Stock

  • Quick Facts

  • Documentation

  • Services

Battery type & OPERATING ENVIRONMENT

AGM (VRLA)
Title

CAPACITY

6 Ah @ 20 Hr Rate to 1.75 VPC @ 77ºF (25ºC)

13.5 A Constant Current @ 8 Hr Rate to 1.75 VPC @ 77ºF (25ºC)

108 Ah @ 8 Hr Rate to 1.75 VPC @ 77ºF (25ºC)
Title
Title

design life & warranty

10 Years Design Life
4 Year Full 6 Pro Rata Warranty
Title

DIMENSIONS

Title

certifications & compliances

TAA Compliant, UL1778, UL1989, UL924, NEBS GR63 CORE, O, UL94 V-0
Title

industries

Telecom

Specifications

view more in-depth details on applications & specifications

C&D Tel Long Duration TFA Installation Operation Manual.pdf
C&D Tel Long Duration Series Specification Sheet.pdf
C&D Tel Long Duration Series 10 Year Warranty.pdf
Title

safety

view more in-depth details on safety features & certifications

Safety C&D Tel Long Duration Safety Data Sheet.pdf
Safety C&D Lead Electrolyte Amounts.pdf
2022 C&D VRLA AGM Safety Data Sheet.pdf

auditing & safety

compliance packages

spill containment systems

spill clean up / remediation

Title

rentals & emergency

containerized rentals

temporary battery strings & equipment rentals

disaster recovery & emergency response
Title

installation

Title

microgrid design

scalable battery energy storage systems (bess)

feasibility assessment & budgeting

system design, install, & maintenance
Title

technical

capacity & acceptance testing

dc power engineering & training

preventative, contract, & scheduled maintenance programs

Title

Removal, Upgrades, & recycling

battery removal, replacement, & recycling

removal & cable mining

upgrades & transition work

C&D Technologies TEL12-115FN Long Duration VRLA Battery - C&D TEL Long Duration Series

C&D Technologies’ TEL Long Duration Series Batteries are Valve Regulated Lead Acid (VRLA) that are designed for long, reliable service life through extensive life-cycle testing to provide essential standby power for your critical telecommunications applications. The batteries in this long duration series are Telcordia-tested, qualified to meet superior standards on extensive life cycles, and ensure the longest and most reliable service life possible.

Key Features & Benefits

  • Multicell design for ease of installation and maintenance
  • Telcordia certified service life exceeding 10 years
  • UL-recognized components
  • Not restricted for air transport - Classified as non-hazardous material, complies with IATA/ICAO Special Provision A67
  • Not restricted for surface transport - Classified as non-hazardous material, complies with DOT-CFR Title 49 parts 171-189
  • Not restricted for water transport - Classified as non-hazardous material, complies with IMDG exception 238

Applications

  • Telecommunications
  • Wireline
  • Wireless
  • Customer Premise / PBX
  • Broadband
  • Microwave Repeaters
  • Indoor/Outdoor Installations
  • Cabinet Systems
  • Rack Systems

C&D TEL12-115FN Construction Details

  • Valve Regulated Lead Acid (VRLA) Absorbed Glass Mat (AGM) battery
  • Absorbent Glass Mat (AGM) technology for efficient gas recombination 99% plus
  • Flame-arresting, one-way pressure-relief vent for safety and long life
  • Thermally welded case-to-cover bond to ensure a leak-proof seal
  • Flame-retardant polypropylene case and cover compliant with UL94 V-0 > oxygen index

Specification Details for TEL12-115FN by C&D


ATTRIBUTES DETAILS
General Info
Chemistry
AGM (VRLA)
Voltage
12 V
Capacity
115Ah @ 8 Hour Rate
Cells Per Unit
6 cells
Dimensions
    - Overall Length
    - Overall Width
    - Overall Height

20.12 inches / 511.00 mm
  4.33 inches / 110.00 mm
  9.25 inches / 235.00 mm
Weight
73.00 lbs / 33.00 kgs
Container Type
POLY-FR
Terminal Type
Front Access M6
Design Life
10 year design life
Warranty
4 Year Full, 6 Year Pro Rata
Electrical Specifications & Performance Characteristics
Float Voltage
13.50 - 13.80 VDC average per 12V unit @ 77°F (25°C)
Operating Temperature Ranges
Nominal: 74°F to 80°F (23°C to 27°C)
Discharge Temperature: -40°F to 160°F (-40°C to 71°C)
Charge Temperature: -10°F to 140°F (-23°C to 60°C)
Specific Gravity
1.300
Electrolyte
Sulfuric Acid
Construction Details
Container and Cover Material
Flame-retardant polypropylene case and cover compliant with UL94 V-0 > oxygen index
Separators
Absorbent Glass Mat (AGM) Separators
Safety Vent System
Flame-arresting, one-way pressure relief vent

Certifications & Safety Compliances

Options & Accessories

  • Contact a member of the Power Storage Solutions Sales Team for additional information on available options and accessories.
